Stainless steel mixing tank for fruit juice
1. Application scope
Used in food and beverage industry equipment, cleaning production equipment.
2. Capacity
300L to 2000L
3. Equipment describe
Made of SUS304 stainless steel, totally consist with food safety requirements.
Controlled by PLC and equip with automatic cleaning system.
4. Main equipment
Hot water tank, acid tank, alkali tank, auxiliary material tank, heat exchanger, temperature control, steam trap, control valve, diaphragm pump, pneumatic valve, liquid level control, metering system, automatic electric control system
5. Basic parameter
Name | Stainless steel storage tank, mixing tank, buffer tank |
Material | SUS304 stainless steel |
Mixing method | Flat leaf, inclined blade, cut leaf, curved blade, can be customized according to customer's specific situation |
Control | Manual / automatic, flow can be set and displayed |
Temperature control | Automatic control, multi-layer structure, automatic control of cold and hot water |
DO control | Using imported electrode, speed can be controlled |
Feeding control | PID fully automatic control, automatic measurement |
Foam control | Full automatic PID monitoring and alarm, automatic adding foam agent |
Pressure control | Manual / automatic |
Mixing control | High performance slurry, plasma, AC motor, frequency converter |
Installation | Vertical and horizontal optional |
Volume | 300L | 400L | 500L | 600L | 800L | 1000L | 1500L | 2000L |
Diameter (mm) | Φ800 | Φ800 | Φ900 | Φ1000 | Φ1000 | Φ1000 | Φ1200 | Φ1300 |
Height (mm) | 600 | 800 | 800 | 800 | 1000 | 1220 | 1220 | 1500 |
Power (kw) | 0.55 | 0.55 | 0.75 | 0.75 | 0.75 | 0.75 | 1.5 | 2.2 |
Rotational Speed | 36 Rev / min | |||||||
Pressure | ≤0.09Mpa | |||||||
Temperature | <100℃ | |||||||
Accessory | Sanitary manhole, cleaning ball, safety valve, pressure gauge |
